Adobe Analytics

Adobe Campaign and Adobe Analytics integration guide

Connect Adobe Campaign to Adobe Analytics: what data flows each way in Campaign v8, Classic and Standard, the requirements and the setup step by step.

Rafael CampoamorDigital Marketing Freelancer
8 min read · 1817 words

The Adobe Campaign and Adobe Analytics integration connects your email deliveries to what recipients do on your site. Campaign sends its delivery metrics (sent, opened, clicked, bounced) and campaign attributes to Analytics, and in Campaign v8 and Campaign Classic, Analytics sends behavior segments back to Campaign for re-marketing.

How you set it up depends on which Campaign you run: v8 and Classic use the Web Analytics connectors add-on, Campaign Standard uses a dedicated external account. This guide covers the three, with the requirements, the data each one moves and the steps, all from Adobe’s Experience League documentation. Adobe’s product page on analytics integration gives the commercial overview.

Which integration you have

Campaign v8Campaign Classic v7Campaign Standard
MechanismWeb Analytics connectors add-onWeb Analytics connectors packageExternal account “Share KPIs with Adobe Analytics”
Campaign → AnalyticsEmail indicators and campaign attributesCampaign indicators and attributesEmail KPI data
Analytics → CampaignSegments for re-marketingSegments on post-campaign behaviorNot in this integration (see Triggers below)
Login requirementIMSIMSWeb services credentials from Analytics
Message Center (transactional)Not compatibleNot compatibleEmail deliveries only

The rest of the guide follows that split, because each version has its own documentation and its own setup.

What Campaign sends to Analytics

Campaign v8 and Classic

The connector sends two kinds of data for each delivery.

Indicators, the counters: @toDeliver, @processed, @success, @totalRecipientOpen, @recipientOpen, @totalRecipientClick, @personClick, @recipientClick, @optOut and @error.

Attributes, the labels: the delivery’s internal name and label, the operation label and nature (only with the Campaign package), three free tags (webAnalytics/@tag1 to @tag3) and the contact date.

On the Analytics side they land in two conversion variables and ten success events:

Analytics componentWhat it holds
Conversion variable 1Internal campaign name (cid)
Conversion variable 2Broadlog table ID (bid)
Success events (10)Clicked, Opened, Person clicks, Processed, Scheduled, Sent, Total bounces, Unique clicks, Unique opens, Unsubscribed

When you submit the external account, Campaign creates a data source, calculated metrics, re-marketing segments and classifications in the mapped report suite.

One detail that explains odd numbers: Campaign sends metric data as a delta from the last snapshot, so a day can show a negative value.

Campaign Standard

Campaign Standard shares KPI data and lets you enrich tracking formulas with Analytics parameters. Once Campaign reporting is enabled, the report suite gets an Adobe Campaign report, five classifications, nine metrics and six dimensions:

TypeComponents
MetricsSent, Opened, Clicked, Delivered, Unique Open, Unique Click, Unsubscribed, Total Bounces, Executed Delivery ID Instances
DimensionsCampaign ID, Campaign Label, Delivery ID, Delivery Label, Executed Delivery ID, Executed Delivery Label
ClassificationsDelivery ID, Delivery Label, Campaign ID, Campaign Label, Executed Delivery Label

Delivery ID includes the master deliveries of recurring and transactional deliveries; Executed Delivery ID includes only deliveries that ran. Pick the second when you count what was actually sent.

What Analytics sends back to Campaign

In Campaign v8 and Classic the connector also recovers web events from Analytics, such as purchases and cart abandonment, and turns them into segments for re-marketing. Two settings on the external account’s Advanced tab control it:

Each segment needs its own re-marketing campaign, created from the “Re-marketing campaign” template and linked to the external account. These campaigns start automatically once Campaign recovers the segments, and the “Re-marketing efficiency” report shows conversions against cart abandonments.

Campaign Standard has no return path in this integration. For behavior-based emails it uses a separate one: Analytics Triggers, which Adobe describes as sending personalized emails in response to behavior tracked on your site within 15 minutes.

Requirements

Campaign v8 and Classic

Campaign Standard

Setup in Campaign v8, step by step

  1. Create the report suite. Start by logging into Adobe Analytics, then go to Admin › All admin › Report suites › Create new, with the report suite ID, site title, time zone, go-live date and estimated page views per day.
  2. Prepare the variables. Configure the two conversion variables (cid, bid) and the ten success events listed above.
  3. Create a classification set. In Components › Classification sets, create a Primary set, add the people who get job notifications, and subscribe the report suite and the campaign name variable.
  4. Create the external account in Campaign. Administration › Platform › External accounts › New, type Web Analytics, integration Adobe Analytics. Map the email, IMS Org, Analytics company and report suite; then map the two eVars and the ten events, and submit.
  5. Enrich the URL formula. Use “Enrich the formula…” to set the campaign IDs and the domains to track. An override exists for experts, but an error in it can stop deliveries.
  6. Review the Advanced tab. Adjust lifespan and persistence if the defaults do not suit your purchase cycle.
  7. Turn it on per delivery. In the delivery properties, open the Web Analytics tab and select the external account.

The campaign ID and broadlog ID reach Analytics through JavaScript on the landing page or through processing rules, so the landing pages must read them. If you rename components in Analytics later, the Data Settings tab and its Sync button pick up the change.

Setup in Campaign Standard, step by step

In Analytics:

  1. Go to Admin › Report Suites, select the suite, then Edit Settings › Adobe Campaign › Adobe Campaign Reporting, and click Enable Campaign Reporting.
  2. Review the new Adobe Campaign Executed Delivery ID report.
  3. Configure the classifications under Edit Settings › Adobe Campaign › Adobe Campaign Classifications.

In Campaign Standard:

  1. Go to Administration › Application settings › External accounts.
  2. Open Share KPIs with Adobe Analytics.
  3. Enter the web services user name and shared secret, then click Refresh report suites.
  4. Choose the report suite in Analytics default report suite.

The technical workflow “Share KPIs with Adobe Analytics” starts automatically, is incremental, pushes the previous day’s data and can use broadlogs up to six months old. To switch the integration off, clear Enabled on the external account.

Limits and mistakes to avoid

If session counts look wrong after launch, Adobe’s troubleshooting guide covers the common causes.

Reading the results in Analysis Workspace

With the integration live, a freeform table with the campaign name variable as the dimension and Sent, Opened and Clicked next to Visits and Orders answers the question the integration exists for: which email drove revenue, not only opens. That is the email slice of Adobe marketing analytics; the other channels still depend on tracking codes in your ads and social links, which our guide to the Adobe Analytics campaign tracking code covers. To compare first and last touch across email and the rest, see attribution models in Adobe Analytics.

Analytics also connects to other Adobe products the same way; Adobe’s guide on connecting Adobe Analytics shows the Commerce Intelligence case, and its customer success stories show how other organizations use the stack.

Keep the landing side honest

The connector moves Campaign’s numbers; the weak point is usually the landing page. If a release drops the script or processing rule that reads cid and bid, Campaign keeps reporting opens and clicks while Analytics stops connecting them to visits, and nobody notices until a revenue report looks off.

Trackingplan watches the Adobe Analytics hits your real traffic sends and warns about missing or dropped events, naming convention violations and unexpected traffic drops as they appear, so a broken landing page is a warning the same day, not a question at the end of the quarter. For a broader view of the platform, our Adobe Analytics guide covers reports, segments and attribution.

FAQ

What does the Adobe Campaign and Adobe Analytics integration do?

It sends email delivery metrics and campaign attributes from Adobe Campaign to Adobe Analytics, so opens, clicks and bounces sit next to the visits and orders those emails drove. In Campaign v8 and Campaign Classic it also works the other way: Analytics returns behavior segments, such as cart abandoners, for re-marketing campaigns.

Which Adobe Campaign versions integrate with Adobe Analytics?

All three that Adobe documents: Campaign v8 and Campaign Classic v7 through the Web Analytics connectors add-on, and Campaign Standard through an external account that shares KPIs with Adobe Analytics. Campaign Standard sends data to Analytics only and works with email deliveries only.

What do I need before connecting Adobe Campaign to Adobe Analytics?

For Campaign v8 and Classic: the Web Analytics connectors add-on installed through its package, an IMS (Adobe ID) connection to Campaign and Analytics permissions to create report suite components. Managed Cloud Services customers must contact Adobe to connect Campaign with the Experience Cloud. For Campaign Standard: Campaign reporting enabled in the report suite and a functional administrator in Campaign.

How long does Campaign data take to appear in Adobe Analytics?

In Campaign v8 the technical workflow runs daily at 4 AM and data can take up to 24 hours to reach Analytics. For Campaign Standard, Adobe’s Analytics documentation says data syncs every 15 minutes through a data source provisioned for the integration.

Does the integration work with transactional messages?

No. Adobe documents the Web Analytics connector as not compatible with transactional messaging (Message Center) in Campaign v8 and Campaign Classic, and the Campaign Standard integration covers email deliveries only.
